Z690 AORUS ELITE AX DDR4
BUILD SMART. GO ELITE.
Ever wonder why your system underperforms? You may be surprised how a motherboard could critically bottleneck the system performance, especially when it falls short on both the power and thermal design. With a limited budget, it is even more important to spend it wisely. Introducing AORUS ELITE motherboards, featuring the best-in-class digital power design, the best-in-class full-metal heatsink, and the best-in-class DDR4 XMP compatibility. It only takes a small step-up to be the best-in-class. Build Smart. Go ELITE.
OVERVIEW
PERFORMANCE
THERMAL
CONNECTIVITY
PERSONALIZATION
ULTRA DURABLE
WIFI6 802.11ax
DisplayPort
HDMI
Rear USB 3.2 Gen2x2 Type-C®
2.5 GbE LAN
Advanced Thermal Design
- Fully Covered MOSFET Heatsinks
- 5 W/mK Thermal Conductivity Pad
- Integrated IO Shield
4* M.2 Ultra Storage Performance Connectors
- 4*PCIe 4.0 x4 M.2
- 2*Enlarged Thermal Guards
AMP-UP Audio
- ALC1220-VB Audio
- High-End Audio Capacitor
- Audiophile Grade WIMA Capacitors
RGB FUSION 2.0
- Addressable LED Header*2
- RGB LED Header*2
16+1+2 Direct Digital VRM Design
- 70A Power Stage
- PCIe 5.0 Ready PCB
- Premium Choke and Capacitor
- 6-Layer & 2X Copper PCB
Solid Pin Power Connectors
- 24 pin ATX Power Connector
- 8+4 pin CPU Power Connector
Dual Channel DDR4, 4 DIMMs with Ultra Durable Memory Armor
Supports 12th Gen. Intel Core™ Processors
Front USB3.2 Gen2 Type-C® for Connecting Devices
Next Generation PCIe 5.0 Design
- 1*PCIe 5.0 x16 SMD Slot
- Ultra Durable™ SMD PCIe 5.0 Armor
6*SATA 6Gb/s
Q-FLASH Plus Onboard Button
Direct Digital VRM Design
PCIe 5.0 Design
DDR4 XMP
RAID Storage
Hybrid Cores Optimization
UNPARALLELED PERFORMANCE
With technology moving so fast, GIGABYTE still keep up with the latest trends and provide our customers with advanced features and latest technology. GIGABYTE Z690 Series motherboards come with upgraded power solution, latest storage standards and outstanding connectivity to enable optimize performance for gaming.
Thermal Design
Fully Covered MOSFET Heatsink
M.2 Thermal Guard II
2X Copper PCB
Smart Fan 6
ADVANCED THERMAL SOLUTION
GIGABYTE Z690 Series Motherboards’ Un-throttled performance is guaranteed by innovative and optimized thermal design to ensure the best CPU, Chipset, SSD stability and low temperatures under full load application and gaming.
2.5 GbE LAN
WIFI6 802.11ax
USB3.2 Gen 2×2 Type-C®
AMP-UP Audio
NEXT GENERATION CONNECTIVITY
GIGABYTE Z690 Series Motherboards let you experience ultimate connection flexibility and blazing data-transfer speed with next generation network, storage, and WIFI connectivity.
RGB FUSION
UEFI BIOS
EASY TUNE
System Information Viewer
DEFINITIVE AESTHETICS
GIGABYTE motherboards bundle several useful and intuitive software to help users to control every aspect of motherboard and provide customizable lighting effect with outstanding aesthetics to fit your unique personality.
Q-Flash Plus
Solid Pin
ULTRA DURABLE
GIGABYTE Ultra Durable™ features its product durability and high-quality manufacturing process. GIGABYTE motherboards use the best components and reinforce every slots to make each of them solid and durable.
Key Feature
- Supports 12th Gen Intel® Core™ Series Processors
- Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
- Direct 16+1+2 Digital VRM Design with 70A Power Stage* and Tantalum Polymer Capacitor
- Shielded Memory Routing to Avoid Interference
- Fully Covered Thermal Design with High Coverage MOSFET Heatsinks
- Onboard WIFI 6 802.11ax 2T2R & BT5 with AORUS Antenna
- AMP-UP Audio with ALC1220 and WIMA Audio Capacitors
- Fast 2.5GbE LAN with Bandwidth Management
- 4x Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Enlarged Thermal Guards
- SuperSpeed USB 3.2 Gen2x2 TYPE-C® delivers up to 20Gb/s transfer speeds
- RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
- Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
- Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card
*Power Stage maximum current capacity is based on VCORE Phase.
